Alpha-InnoTec LWDV - System Commissioning Steps

13
Subject to technical amendments without prior notice | 83055800cUK – Translation of the operating manual | ait-deutschland GmbH
ConrmtheIBN–assistantormakethesettingvia:
Service>>Settings>>Energye󰀩cient
circulation pump:
The“Setoverowvalve”menuitemissetbydefaultto
“No”.Theoverowvalveadjustmentfunctionisdeac-
tivated.
● The UWP control signal is the indication of the
currently required pump capacity as a %
● Theactualowrateisthecurrentowrate(meas-
uring accuracy +/- 200 l/h)
1. Fully open the overow valve, close the heating
circuits.
2. If the “Set overow valve”menuitemissetfrom
“No” to “Yes”, the circulation pump is activated to
100% – and the pump starts up.
3. If the control signal UWP reaches 100%, close
theoverowvalvetotheextentthatthemaximum
owrate(seetechnicaldata)canbeensured.
Overowvalve(2)rotary-pushbutton(1)
4. Ifyouexitthe“Setoverowvalve”menuoratthe
latest after one hour, the circulation pump switch-
es back to standard regulation.
5. Open valves to heating circuit.
11 Commissioning
 The relevant planning and design data of the system
is documented in full.
 The relevant energy supply company has been
notiedoftheoperationoftheheatpumpsystem.
 The system is air-free.
 Installation check using the rough checklist has
been completed successfully.
1. Ensurethatthefollowingpointsarefullledcom-
pletely:
● Clockwiserotatingeldispresentfortheload
supplyatthecompressor(for400Vconnec-
tion only).
● The system is installed and mounted accord-
ing to this operation manual.
● The electrical installation has been carried out
properly according to this operation manual
and the local regulations.
● The power supply for the heat pump is
equipped with an all-pole circuit-breaker with
atleast3mmcontactspacing(IEC60947-2).
● The tripping current is complied with.
● Theheatingcircuithasbeenushedandvented.
● All shut-o󰀨 devices of the heating circuit are
open.
● The pipe systems and components of the sys-
tem are tight.
2. Carefully ll in and sign the notice of completion
for the heat pump systems.
3. In Germany and Austria: Send the notice of comple-
tion for heat pump systems and rough checklist to
the manufacturer’s factory customer service depart-
ment.
In other countries: Send the notice of completion
for heat pump systems and rough checklist to the
manufacturer’s local partner.
4. Arrange for the heat pump system to be com-
missioned by the manufacturer’s authorised after
sales service for a fee.
