SPECIFICATIONS FOR THE SERIES 800 THERMOELECTRIC COOLER
CONTROLLER
Two yearsWarranty
0°C to 50ºC (32°F - 122°F)Operating Temperature
Thermoelectric Cooler, AC Power, Power Booster ModuleI/O Connections
Thermoelectric Cooler, Temperature Sensor, AC Power, Power Booster
Module (PBM), optional EIA/RS-232/485 (using MODBUS
1
protocol)
I/O Connections
4.9” H X 7.2“ W X 10.6” LDimensions
12 pounds maximum (150 watt instrument)Weight
Two (2) FansInternal Cooling
115/230 Volts AC, internally selectable, 47 - 63 Hz.AC Power
Thermistor 100 Kohm range, 0 to 99.99K or 10 ohms
1 Megohm range, 0 to 999.9K or 100 ohms
For other sensors, such as RTDs, thermocouples, AD590/592 and
LM35/135/335 sensors, the resolution is 0.1 ºC.
Display Resolution
Thermoelectric Cooler temperature and set-point temperature in ºC or ºF
(user-selectable) with an RTD, thermocouple, AD590/592 and LM135/335.
For a thermistor, the display is in Kohms.
Display
Two 4 digit LED displays, RED - for actual temperature
GREEN - for set point temperature
Front Panel Displays
< 1 mANoise and Ripple
< 0.002º CLong Term Stability
Higher and lower temperatures can be measured depending upon the
sensor type. Please refer to Appendix A for details on the
temperature ranges available for each sensor type and an example of
a custom sensor type.
Thermistors can operate on one of two ranges (0 to 99.99 Kohms and 0 to
999.9 Kohms). Integrated temperature sensors (AD590/592 and
LM35/135/335) operate from: -50ºC to 150ºC.
Sensor Temperature Ranges for
Standard Sensors
100 ohm RTD, Types E, J, K, N, and T thermocouples, thermistor,
AD590/592, and LM35/135/335 as well as external voltage and current
inputs.
Temperature Sensors
30 W, 60 W, 90 W, 120 W, and 150 W.Maximum Output Power for
Controllers & Power Boost Modules
2, 4, 6, 8, or 10 amperes.Maximum Output Current
+15 Volts DC.Compliance Voltage
Uni-polar or Bi-polar, constant current, PID (Proportional, Integral,
Derivative) with Auto-tuning. User can select P, or P&I control only.
Control
ALPHA OMEGA INSTRUMENTS CORP. Instruction Manual
Series 800/850 Thermoelectric Cooler Controller Page 2
1
MODBUS is a registered trademark of Modicon, Inc., Industrial Automation Systems.
