Alpha Omega Instruments 800 Series User Manual

Front Panel Controls
Hardware Concepts
Auto-tuning
Sensor Configuration Table
Sensor Programming & Configuration
Thermistor
0 to 1M Thermistor
AD590
LM35
LM135/235/335
100 ohm 3 Wire RTD
Voltage
Current
Thermocouples (all types)
Section 4.0
TEMPERATURE SENSOR SELECTION & SETUP
Before proceeding, have the mating connector supplied with the Series 800/850 TEC
Controllers ready to be wired.
The following pages illustrate the types of temperature sensors supported by the
Series 800/850 TEC Controllers .
Please reference the Sensor Configuration Table on page 20 while going through the
setup to insure that the sensor is wired correctly.
Please also note that the factory pre-configures the Series 800/850 TEC Controllers
to work with the sensor type specified (if applicable) at the time of purchase.
Items covered in this section:
ALPHA OMEGA INSTRUMENTS CORP. Instruction Manual
Series 800/850 Thermoelectric Cooler Controller Page 17
