Instructions for the installer
3.4 PACKAGING
e ARES Tec ErP boiler is supplied assembled in a sturdy cardboard
box.
Once the two straps have been removed, slide the box
o from the top and make sure the contents are intact.
Packaging materials (cardboard box, straps, plastic
bags, etc.) constitute a potential hazard and must be
kept out of the reach of children.
e manufacturer will not be held liable in case of
damage caused to people, animals or property due to
failure to observe the above.
OBLIGATION!
Wear protective gloves
- Only transport the boiler using appropriate transport
means, for example a trolley with xing strap.
- When the boiler is shipped, it must be secured to the
transport equipment.
- Protect all parts against impacts, if they must be
transported.
- Follow the transport instructions on the package.
- e boilers must always be lied and carried with a
trolley or suitable transport equipment.
To take the boiler o of the pallet it is necessary to use a jib crane, to
avoid damaging it.
- Remove the casings and harness it using slings "A" g. 3 being careful
to pass the slings through the load bearing crossbeams of the frame
- Tie the slings to the jib "B". Perform these operations with caution.
Composition of packaging:
on the le side of the boiler:
- e ue exhaust manifold.
- A cardboard box containing:
- Gasket between pan and terminal
- Collar gasket (Ø 250) Ø 300
- Two bends + one T + plastic cap for condensate drain
- Screws required to secure the ue terminal
- e probes: external, ow, storage tank.
- Flue inspection cap.
- Plate and fairlead for power output.
- A cardboard box containing:
- Flanges
Inside the rear side of the casing:
- Condensate drain trap pipes (1 m).
Above the boiler cover:
- A plastic bag containing:
- Installer and maintenance technician instructions handbook
- HSCP control unit user handbook
- BCM 2.0 user handbook
- SHC book
- Warranty certicate
- Hydraulic test certicate
- Pins to block the set of fans in raised position
Model A (mm) B (mm) C (mm)
Gross
Weight (kg)
440
550
660
770
900
1263
1531
1531
1799
1799
1120
1120
1120
1120
1120
1515
1515
1515
1515
1515
585
643
707
806
858
