Service manual AlphaCom XL transceiver Rev. 1.4 10-08-2011 Blz. 10/74
Industry
Security Class
Regulations for Alarming / transmission
1
AL1
2
AL1
3
AL1
3*
AL2
4
AL2
4*
AL3
Alarm transmission
AL0
None
AL1
Alarm transmission according to NEN EN 50136-1-
1 level AL1
AL2
Alarm transmission according to NEN EN 50136-1-
1 level AL2
AL3
Alarm transmission according to NEN EN 50136-1-
1 level AL2 accompanied with a back-up
transmission channel according to level AL1 via a
different transmission method (for example GPRS)
The above information is based on the „Verbeterde Risicoklassenindeling VRKI 2007‟. For a full overview,
see www.hetccv.nl.
If all parameters have been set correctly the AlphaCom XL can be used in all cases !. In a AL3 situation the
GPRS module must be present.
According to the EN50136-1-1 there are specific rules and regulations that also apply for alarm transmission
over IP. The AlphaCom XL complies with regulations: D4, M4, T5, A3, S2, I3. A higher number indicates a
better performance.
The regulations for AL1 are: T2, T2, T2, D2, M2, S1, I2.
The regulations for AL2 are: T4, T2, T3, D3, M3, S2, I3
The regulations for AL3 are: primary transmission AL2 + back-up AL1
Most of the features of the AlphaCom XL with respect to the above mentioned information are determined
by the hardware design of the AlphaCom XL. It is therefore not necessary to fill in specific parameters to
comply. The only point of consideration is the Supervision Interval (polling time) and the periodic
testmessage, see Configuration IP dialer.
It is strongly recommended when using AL1 to program the Supervision Interval to a value not higher than
900 (15 minutes) and for AL2 no higher than 90 seconds.
The Periodic Testmessage is the automatic test message generated by the AlphaCom itself. In the Standard
Settings this is not necessary. When the AlphaCom XL is used in a AL2 application this value must be
programmed in the Backup Settings to 1440 minutes (the regulation states less than 1x per 25 hours). This
setting will determine that the backup medium, even though it is not active, will send a message 1x per 24
hours. With this combination, the AlphaCom XL complies with even the highest level AL3.
