Service manual AlphaCom XL transceiver Rev. 1.4 10-08-2011 Blz. 19/74
Wiring diagram for connection between AlphaCom XL and Galaxy XL serie of control panels:
Wire
number
Name
*
Meaning
Connector pin at Galaxy XL series
1
nc
not used
2
nc
not used
3
TX
„1‟ signal from AlphaCom XL to
the serial printer interface. By
this wire, the printer interface
detects an operating serial link
and messages can be transmitted
from the Galaxy to the
AlphaCom XL.
7 (DTR)
4
nc
not used
5
RX
Serial data from Galaxy printer
interface to the AlphaCom XL.
3 (TX)
6
nc
not used
7
nc
not used
8
nc
not used
9
GND
Ground
9 (GND)
10
nc
not used
*
nc = not connected
Take care: Alphatronics b.v. cannot be held responsible for the correct functioning of this serial connection,
neither for the correct information regarding the wiring of 3
rd
party equipment. Please contact the local
distributor in case of any doubt. Setting up the serial port at the AlphaCom XL for reception of logprinter
messages is described with the RS-232 ports.
