Service manual AlphaCom XL transceiver Rev. 1.4 10-08-2011 Blz. 2/74
Technical details for the AlphaCom XL transceiver:
Dimensions: 163 x 92 x 18 mm (l x w x h).
Currentdrain active: 135mA. (no GPRS)
*)
Currentdrain peek: 275mA. (no GPRS)
*)
Currentdrain active: 145mA. (incl. GPRS)
**)
Currentdrain peek: 385mA. (incl. GPRS)
**)
Power supply: 12-16VDC
Working temperature: 0 tot +50 C
Humidity: max. 85% relative humidity
LAN connection: 10 Mbit/s
Articlecode: 003630
Technical details regarding relay outputs. Details which are based on outputs 2, 3 and 4, which can be
activated by the user remotely, are not part of the security concept and were not subject to official testing by
the testing authorities. It is highly recommended to power external devices through an external power supply
and thus not draining cuurent from the AlphaCom XL transceiver.
Currentdrain relay 2 to 4: 65mA (active).
Maximum current drain: 500mA (+12V terminal to relay 4)
*)
no GPRS means, that the GPRS transceiver is not programmed. The GPRS module is present on the pcb
board, but not active.
**)
incl. GPRS means, that the GPRS transceiver has been programmed and the GSM module is enrolled in
the GPRS network. The module is stand-by and waiting to send a message.
De ALPHACOM XL transceiver complies with the following European regulations:
EMC emission EN301489-3 2002
EMC immunity EN50130-4 2003
Radio transmission EN300220-3
Telephone TBR21 1998
*)
Safety class European norm EN60950
Alarm transmission EN50136-2-1 1998
ATS classes 50136-1-1 D4, M4, T5, A3, S2, I3
**)
*)
the PSTN connection complies with the TBR21 norm, but is not connected to any public telephone system
or public telephone network. The PSTN connection generates its own signals to simulate a public telephone
exchange, so alarm messages sent by the analog dialer of the security alarm system, can be received and sent
via an IP connection.
**)
see chapter „Settings according to local requirements‟ for the correct settings of this device according to
the required local regulations for this specific installation. Also here you will find the settings for the dutch
regulations according to the AL1, AL2 and AL3 norm.
The AlphaCom XL is manufactured according to the most modern production methodes and complies with
RoHS standards. This means that the components used and the soldering process are lead-free.
