Service manual AlphaCom XL transceiver Rev. 1.4 10-08-2011 Blz. 6/74

Table of Contents

Table of Contents4
Introduction7
Figure 1: Alphacom XL Transceiver7
General8
Settings Accoridng to Local Requirements9
- Forcing an Alarm Message Manually9
- Dutch Regulations AL1, AL2 and AL39
Quick Installation Guide11
Alphacom Xl Programming12
Hardware Installation13
- Figure 2: Alphacom XL Connections13
- Figure 3: Schematics PSTN Tamper Loop14
- Figure 4: Jumper for PSTN Tamper Loop14
- PSTN Tamper Loop14
- Analog Inputs15
- Figure 5: Jumper Settings for Relay16
- Relay Outputs16
- Connecting Serial Logprinter from Control Panel18
- Figure 3: Connection Serial Logprinter to Alphacom XL18
- Figure 4: Serial Cable from Logprinter to Alphacom XL18
Alphacom Xl Programming20
- Alphatronics Equipment Discovery Tool24
- Log in24
- Status Screen26
- Ethernet Configuration27
- GPRS / GSM Configuration29
- Webserver Configuration31
- Configuration IP Transceiver 133
- Configuration IP Transceiver 234
- Monitoring Settings / Fault Relay35
- Configuration Inputs 1 to 636
- PSTN Interface Configuration38
- Serial Port Configuration40
- Relay Output Configuration43
- Restore Factory Default Settings44
- Relay Control by User46
Testing the Alphacom Xl47
- Back-Up Function of Transceiver 147
- Transceiver 2 as Dual Transmission47
- PSTN Back-Up Function48
- LED Indications on the PSTN-2-IP48
- DIPSWITCH Settings of the Alphacom XL49
- Firmware Upgrade for the Alphacom XL (Bios Flash)50
- Figure 6: Connections.for Flashing Firmware (Bios-Update)53
APPENDIX A Installing the FLASH Program57
APPENDIX B Making a Reservation on a DHCP Server64
Figure 6: Straight through Cable Wiring66
Figure 7: Netwerk Cross-Over Cable Wiring66
APPENDIX C Cable Wiring66
APPENDIX D Reserved Port Numbers67
Appendix E68
APPENDIX F Compatible Control Panels71
APPENDIX G SIA-Codes72
APPENDIX H Release Notes73
Register73
