16-EN
Adjusting Subwoofer Level/Bass Level/
Treble Level/Balance (Between Left and
Right)/Fader (Between Front and Rear)/
Defeat
1
Press AUDIO repeatedly to choose the desired mode.
Each press changes the mode as follows:
SUBWOOFER
*1/*2
BASS LEVEL
*2/*3
TRE LEVEL
*2/*3
BALANCE
FAD ER DEFEAT VOLUME SUBWOOFER
*1 When the subwoofer mode is set to OFF, its level cannot be
adjusted, refer to “Turning Subwoofer ON/OFF” on page 17.
*2 Not displayed when BASS ENGINE SQ mode is selected. (Refer
to “Setting BASS ENGINE SQ mode” on page 19)
*3 Adjustable only when DEFEAT is OFF.
Note
• If no operation is performed for 5 seconds, the unit automatically
returns to normal mode.
2
Turn the Rotary encoder until the desired sound is
obtained in each mode.
By setting DEFEAT ON, previously adjusted level settings of BASS
and TREBLE will return to the factory defaults.
Sound Setting
You can flexibly customize the unit to suit your own preference and
usage. From the AUDIO SETUP menu, Audio Setting can be modified.
1
Press and hold AUDIOSETUP for at least 2 seconds to
activate the SETUP mode.
2
Turn the Rotary encoder to select AUDIO, and then press
ENTER.
3
Turn the Rotary encoder to select the desired sound
setting menu, and then press ENTER.
EQ PRESETS
*1/*2/*3
BASS ENGIN
*4
PAR AME TER
*5
9BAND P-EQ
*1/*3/*6
SOURCE VOL HPF
*1/*3
SUBWOOFER
*7
SUBW LPF
*1/*3/*8
SUBW PHASE
*1/*8/*9
SUBW SYS
*3/*8
POWER IC MX SETTING
*1/*3
*1 Adjustment cannot be performed when DEFEAT is set to ON.
*2 Any changes made to either EQ PRESETS or 9BAND P-EQ are
reflected in the others’ settings.
*3 These items are not adjustable in BASS ENGINE SQ mode. If
you want to adjust these items separately, follow the confirm
message select “YES” to exit BASS ENGINE SQ mode, and then
make the setting.
*4 Not displayed when the Audio Setup mode is activated by
pressing BASS.
*5 Not displayed when BASS ENGIN is OFF.
*6 In step 3, after selecting a Band (BAND1 to BAND9) from
9BAND P-EQ adjustment mode. Turn the Rotary encoder to
select the desired item, and then press ENTER to continue to
step 4.
*7 This item is also relative with BASS ENGINE SQ mode when
you adjust sound setting via TuneIt App on a Smartphone.
(Refer to “Adjusting the sound via the Smartphone” on page 21)
*8 These functions are inoperable when Subwoofer is set to OFF.
*9 Not displayed when SUBW LPF is OFF.
4
Turn the Rotary encoder to change the setting, and then
press ENTER.
(e.g. Select SUBW ON or SUBW OFF)
5
Press and hold AUDIOSETUP for at least 2 seconds to
return to normal mode.
Notes
• Adjustment cannot be performed during a call.
•Pressing t returns to the previous Sound menu mode.
• If no operation is performed for 60 seconds, Sound menu mode is
cancelled.
• You can access to Sound menu mode directly by pressing BASS when
BASS ENGIN is set to OFF. (Refer to “Setting BASS ENGINE SQ mode”
on page 19)
10 typical equalizer settings are preset at the factory for a variety of
musical source material. USER settings are created in the 9BAND P-EQ
mode.
USER FLAT (Initial setting) POPS ROCK NEWS JAZZ
ELEC DANCE HIP HOP EASY LIS COUNTRY
CLASSICAL
Note
• The 9-Band, Parametric EQ is used to create the EQ PRESETS settings.
Sound Setting
Subwoofer +0 ~ +15
Bass level −7 ~ +7
Treble level −7 ~ +7
Balance L15 ~ R15
Fader R15 ~ F15
Defeat ON/OFF
Volume 0 ~ 35
/ENTER
AUDIO/SETUP
BASS
Rotary encoder
Use steps 1 to 5 to select the category you wish to modify. For
details on how to change each setting, see the following
sections below.
Equalizer Presets
To Next Page
