Page #21 background imageLoading...
Page #21 background image
21-EN
*14 While calling, and the Voice Mute is activated, the
microphone input will mute instantly and “VOICE MUTE”
will blink. This operation can also be done by pressing .
Refer to “Muting the microphone input quickly (Voice Mute)”
on page 30.
*15 If there is a waiting call, select this item to display the caller’s
Name and waiting number (1 or 2). Press VIEW and the
display will switch.
*16 Select this item to hang up the call.
Notes
•Press r to return to the previous mode.
If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
Applying TuneIt
This units sound tuning is programmable from a connected
Smartphone. It is also possible to download specific parameters for
certain vehicles from Alpine’s TuneIt database stored in the Cloud. Using
the TuneIt App, customized parameters can also be uploaded for others
to share and rate.
Through this unit, it is also possible to receive and respond to
information from Alpines Social Network Service (SNS) available
through the connected Smartphone.
The installed TuneIt App should be launched on the Smartphone before
connection to the head unit.
TuneIt, is downloadable from Apples App Store; the Android user can
download it from Google Play. For details, consult your Alpine dealer.
Before these operations, set ALPINE APP to USB or BT depending on
the connected Smartphone. For details, refer to “Setting the
communication mode with a Smartphone (ALPINE APP)” on page 24.
Notes
The application programme and related specifications and data may be
deleted or terminated without notice.
Some TuneIt functions may not be available if the Smartphone is not in
a service area or receives no signal.
After setting the above procedure, the indicator lights up, and then
you can adjust the unit’s sound function on the Smartphone.
1
Make sure the unit is powered on.
2
Launch the TuneIt App on the Smartphone. Adjust the
unit’s sound accordingly on the Smartphone.
During sound setting, the indicator may blink.
Notes
Volume level cannot be adjusted via the Smartphone.
The setting cannot be done on both the Smartphone and this unit at the
same time. While the sound function of this unit is set via the
Smartphone, sound function settings on CDE-183BT will be displayed
as “APPCONNECT”.
In some situations, such as the unit is powered off or during a call, etc.,
sound setting cannot be done via the Smartphone.
This function may not be available depending on the paired
Smartphone.
Please obey all local traffic laws while using this function.
Some functions may be available in a future version of TuneIt.
Note
Depending on the paired Smartphone, the following functions may not
be available even though the TuneIt version is updated.
Receiving Notification
When the Smartphone connected to this unit receives notification from
Facebook, the unit’s back lighting and the V indicator blinks
(depending on the TuneIt settings on the phone). At the same time, the
user’s name is shown in the display (20 characters maximum). Play back
the notification via TTS (Text To Speech) by the following procedure.
1
While receiving Notification from Facebook, press
VSOURCE button.
Notification Menu screen is displayed.
2
Turn the Rotary encoder to select the desired mode, and
then press ENTER.
LIKE
*1
REPLAY NEXT PREVIOUS TTS VOLUME
*2
*1 Not displayed when the received Notification is Message type.
*2 It can also be set in SETUP section. For details, refer to “Setting
the TTS (Text To Speech) volume” on page 24.
Notes
•Press t to return to the previous mode.
A new received Notification prompt will last for 30 seconds. If there is
no operation within 30 seconds, the unit will return to normal mode.
In some situations, such as the unit is powered off or during a call, etc.,
Notification of the Smartphone will not be prompted by this unit.
Displaying Notification List
You can view the received Notification from Facebook in the connected
Smartphone via this unit.
1
Press and hold VSOURCE for at least 2 seconds.
The received Notification will be displayed according to when it
was posted.
2
Turn the Rotary encoder to select the desired Notification,
and then press ENTER.
3
Then go to step 2 of “Receiving Notification.
Notes
When there is no Notification, “NO NOTIF” will be displayed.
The displayable amount of the Notification list depends on the
connected Smartphone.
If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
Adjusting the sound via the Smartphone
Facebook Notification Function
LIKE: The Smartphone feedbacks to Facebook with “Like”,
and meanwhile, the received Wall Posts or
Comments are played back by TTS (Text To
Speech).
REPLAY: To play back Notification by TTS (Text To Speech)
again.
NEXT: To select the next Notification.
PREVIOUS: To select the previous Notification.
TTS VOLUME: To adjust the playback volume of TTS (Text To
Speech).

Table of Contents

Other manuals for Alpine CDE-183BT

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Alpine CDE-183BT and is the answer not in the manual?

Alpine CDE-183BT Specifications

General IconGeneral
MP3 playbackYes
DVD Audio playbackNo
Playback disc formatsCD audio
Audio formats supportedAAC, MP3, WMA
DIN size1 DIN
Impedance10 Ω
Product colorBlack
Volume controlRotary
Frequency range5 - 20000 Hz
Disc types supportedCD, CD-R, CD-RW
Audio output channels4.0 channels
Equalizer bands quantity9
Maximum power per channel50 W
Signal-to-Noise Ratio (SNR)105 dB
Display typeLCD
Display number of lines1 lines
FM band range87.5 - 108 MHz
LW band range153 - 281 kHz
Supported radio bandsFM, LW, MW
Preset stations quantity30
USB version2.0
Bluetooth version2.1+EDR
Bluetooth profilesA2DP, AVRCP, HFP, HSP, OPP, PBAP, SPP
USB ports quantity1
Headphone connectivity3.5mm
Menu languagesDEU, DUT, ENG, ESP, FRE, ITA, RUS
File format systemFAT 16/32
Key illumination colorMulti
Weight and Dimensions IconWeight and Dimensions
Weight1400 g
Dimensions (WxDxH)170 x 46 x 25 mm
