Page #30 background imageLoading...
Page #30 background image
30-EN
In the call waiting mode, press and hold 1 or 2 for at least 2 seconds to
hang up call1 or call2, and the other call will be answered
automatically. (The action depends on the paired device.)
In the call waiting mode, you can press VIEW to change the display
between waiting number (1or 2) and caller name.
Assign numbers that you dial frequently to presets for quick recall. You
can assign up to six frequently called phone numbers to number presets.
Select a number you want to preset from the Phone Menu
list (PHONE BOOK, DIALLED, etc.). Press and hold any one
of the preset buttons (1 through 6) as the one that you
wish to store the number for at least 2 seconds.
The phone number you selected is stored in presets.
Notes
If the name has several numbers registered in the phone book, press
ENTER after selecting the name. Turn the Rotary encoder to
choose the desired number. Press and hold any one of the preset
buttons (1 through 6) for at least 2 seconds. The selected number is
stored as a preset number.
A total of 30 phone numbers can be stored in the preset memory ( 6
numbers for each Smartphone in the paired device list). If a
Smartphone is deleted from the paired device list, the stored preset
numbers of this Smartphone are deleted, even when it is paired again.
If you store a phone number in a preset with a previously stored
number, the current number will be cleared and replaced by the new
one.
1
Press any one of the preset buttons (1 through 6) that has
had a number stored in the phone mode.
The information (name/number) stored in the preset station is
displayed.
2
Press f or ENTER.
The stored preset number is dialled directly.
While calling, you can adjust the volume.
Turn the Rotary encoder to adjust the volume.
Note
You may need to increase volume from your regular audio listening
source level. However, increasing the volume excessively may result in
feedback. Feedback is directly related to the volume. Turning down the
volume as low as acceptable, will reduce it. Positioning the microphone
in a direction away from the main car speakers (e.g. clipped on sun
visor) may also reduce feedback at high volume.
During a call, activating the Voice Mute function will instantly mute the
microphone input. Your voice will not be heard by the caller.
During a call, press to mute the microphone input.
Press again to bring the microphone input back to its
previous volume level.
During a call, this function allows you to initiate the transfer of the
audio between the Smartphone and the speakers in the car.
During a call, press BAND or press and hold for at
least 2 seconds to switch the call sound between the unit
and Smartphone.
Note
Depending on the Smartphone, this operation may not be possible.
BLUETOOTH Audio Operation
With a Bluetooth compatible Smartphone or music player, its possible to
play and control music playback wirelessly
*
.
* To play back audio, a Smartphone or a portable player conforming to
A2DP (Advanced Audio Distribution Profile) and AVRCP (Audio/
Video Remote Control Profile) is required.
Not all functions work with all devices.
Notes
Set BT IN to ON when you want to use BLUETOOTH Audio function.
Refer to “Setting the BLUETOOTH Connection (BT IN)” on page 26.
During a call, sound on the BLUETOOTH audio source is muted.
If you operate the Hands-free phone (e.g. searching in the phone book)
while using the BLUETOOTH Audio function, BLUETOOTH Audio
playback may be affected.
Press V/SOURCE to select the BT AUDIO mode.
Press or to select the desired Song.
Pressing and holding or will fast backward/fast
forward track continuously.
Note
The action depends on the paired device.
Press .
A playback stops. Pressing again will resume a playback.
Press or to select the desired Group.
Note
This function is not available on all paired devices.
Preset a number in the Phone Menu
(Shortcut dial)
Dialling the preset number
Adjusting the volume when receiving a
Call
Muting the microphone input quickly
(Voice Mute)
Call Switching Operation
Recalling the BLUETOOTH Audio Mode
Selecting the desired Song
Pausing
Selecting the desired Group
