H38x/EN GL/D11 Global Documentation
Page 44/53
DS Agile H38x
8.3 Configuration commands
Configuration command Syntax Example
set IP address setip <ip_addr> setip 192.168.100.12
Set IP netmask setnetmask <ip_addr> setnetmask 255.255.255.0
set gateway IP address setgateway <ip_addr> setgateway 192.168.100.1
Set IP address NTP server setNtpServer <ip_addr> setNtpServer 192.168.0.1
Set NTP frequency setNtpFrequency <seconds> setNtpFrequency 10
Set User Password for Telnet or Uart setUserPassword <pwd> setUserPassword azerty66
Set Root Password for Telnet or Uart setRootPassword <pwd> setRootPassword bnufdp12
Password for SNMP operator level setSnmpOperatorPassword <pwd> setSnmpOperatorPassword tgfd4f8
Password for SNMP admin level setSnmpAdminPassword <pwd> setSnmpAdminPassword kb55fdc
set SNMP Trap IP address setSnmpTrapIp <ip_addr> setSnmpTrapIp 192.168.0.50
Set Synchronisation Mode setSyncrhoMode <mode> setSynchMode 0
Assigning the IP address and Subnet mask is the responsibility of the Network Manager. A
unique IP address should be applied.
The default IP address is 192.168.254.100. Use the “setIp” command as shown in the figure
below to change it.
~ # setIp 192.168.0.33
setting IP to 192.168.0.33
Command line
Answer line
Set the subnet mask numbers using the “setNetmask” command. Typically subnet mask
number fields are either 0 or 255 as in the figure below (255.255.255.0.
~ # setNetmask 255.255.255.0
setting netmask to 255.255.255.0
Command line
Answer line
The “setGateway” command defines the gateway IP address. The gateway address must be
on the same IP subnet as the hosting device. An example is given below:
~ # setGateway 192.168.0.99
Done.
Command line
Answer line
The “setSnmpTrapIp” command sets the IP address for the SNMP trap. An example is given
below:
~ # setSnmpTrapIp 192.168.0.6
setting SNMP trap IP to 192.168.0.6
Command line
Answer line
