2
Figure 1.1. The DE2 Kit Package Content
1-2
Assemble the Rubber Feet
Users can use the attached bag of copper stands, silicon feet cover, and screw to
create suitable feet according to users’s own applications
Assemble a screw, a copper stand, and a rubber (silicon) cover as shown in
Figure 1.2 for each of the 6 screw holes on DE2.
Assemble the plexiglass cover attached if extra protection is desired.
