Altera DE2 Board - Compiling the Design Files

First Lab: DE2 Top-Level and Default Bitstream
45
DRAM_DQ, // SDRAM Data bus 16 Bits
DRAM_ADDR, // SDRAM Address bus 12 Bits
DRAM_LDQM, // SDRAM Low-byte Data Mask
DRAM_UDQM, // SDRAM High-byte Data Mask
DRAM_WE_N, // SDRAM Write Enable
DRAM_CAS_N, // SDRAM Column Addr Strobe
DRAM_RAS_N, // SDRAM Row Addr Strobe
DRAM_CS_N, // SDRAM Chip Select
DRAM_BA_0, // SDRAM Bank Address 0
DRAM_BA_1, // SDRAM Bank Address 0
DRAM_CLK, // SDRAM Clock
DRAM_CKE, // SDRAM Clock Enable
//////////////////// Flash Interface ////////////////
FL_DQ, // FLASH Data bus 8 Bits
FL_ADDR, // FLASH Address bus 20 Bits
FL_WE_N, // FLASH Write Enable
FL_RST_N, // FLASH Reset
FL_OE_N, // FLASH Output Enable
FL_CE_N, // FLASH Chip Enable
//////////////////// SRAM Interface ////////////////
SRAM_DQ, // SRAM Data bus 16 Bits
SRAM_ADDR, // SRAM Address bus 18 Bits
SRAM_UB_N, // SRAM Low-byte Data Mask
SRAM_LB_N, // SRAM High-byte Data Mask
SRAM_WE_N, // SRAM Write Enable
SRAM_CE_N, // SRAM Chip Enable
SRAM_OE_N, // SRAM Output Enable
//////////////////// ISP1362 Interface ////////////////
OTG_DATA, // ISP1362 Data bus 16 Bits
OTG_ADDR, // ISP1362 Address 2 Bits
OTG_CS_N, // ISP1362 Chip Select
OTG_RD_N, // ISP1362 Write
OTG_WR_N, // ISP1362 Read
OTG_RST_N, // ISP1362 Reset
OTG_FSPEED, // USB Full Speed,
// 0 = Enable, Z = Disable
OTG_LSPEED, // USB Low Speed,
// 0 = Enable, Z = Disable
OTG_INT0, // ISP1362 Interrupt 0
