Lab 7: DE2 Control Panel
78
TXT format) for the black&white version of the image – the threshold for
judging black or white level is defined in the BW Threshold.
Image Source R/G/B Band
Filter
B&W
Threshold
Filter
Output Result
(640x480)
Color Picture R/G/B N/A Raw_Data_Gray
Color Picture R/G/B
(optional)
BW Threshold Raw_Data_BW +
Raw_Data_BW.txt
Grayscale
N/A N/A Raw_Data_Gray
Grayscale
N/A BW Threshold Raw_Data_BW +
Raw_Data_BW.txt
Note: Raw_Data_BW.txt is used to fill in the MIF/Intel Hex format for M4K SRAM
11-10 Board Self Tester
DE2 Control Panel’s TOOL page provides users a Board Self Tester. Please note
that the Board Self Tester will erase the content of the Flash Memory during the
testing.
