Altrex 4100 - Configuration Table 4200:1,85 M

10 / 44
EN
IV Rolling Tower 4200
IV.I Configuration table 4200:1,85m
NL
EN 1004-3-8/12-XXXD
1/2 (every 2 meter 1 platform, staggered)
Platform height (m) 2,2 4,2
1
6,2
1
8,2
1
10,2
1
12,2
1
Work height (m) 4,2 6,2 8,2 10,2 12,2 14,2
Description Art.no. Weight (kg)
Frame 135-28-4 303340 5,5 0 0 0 0 0 0
Frame 135-28-7 303370 9,1 2 4 6 8 10 12
Guardrail frame 135-20-2 303320 3,4 2 2 2 2 2 2
Platform 1.85m with trapdoor (wood) 305010 14,0 1 1 1 1 1 1
Platform 1.85m without trapdoor (wood) 305020 14,0 1 2 3 4 5 6
Wheel leg + wheel Ø200 mm 511220 3,3 4 4 4 4 4 4
Diagonal brace 185-28-21 304321 1,9 4 8 12 16 20 24
Horizontal brace 185-4 304304 1,8 6 8 10 12 14 16
Triangular stabilizer up to 4.2m platf. height* 305660 4,0 0 2 0 0 0 0
Triangular stabilizer Standard 4000-Series 305662 7,3 0 0 2 2 2 2
Toe board set 1.35 x 1.85m 305580 9,7 1 1 1 1 1 1
1.35 x 1.85 m
Total weight(kg) including wooden platforms 94 146 196 239 283 326
Platform height (m) 3,2
1
5,2
1
7,2
1
9,2
1
11,2
1
Work height (m) 5,2 7,2 9,2 11,2 13,2
Description Art.no. Weight (kg)
Frame 135-28-4 303340 5,5 2 2 2 2 2
Frame 135-28-7 303370 9,1 2 4 6 8 10
Guardrail frame 135-20-2 303320 3,4 2 2 2 2 2
Platform 1.85m with trapdoor (wood) 305010 14,0 1 1 1 1 1
Platform 1.85m without trapdoor (wood) 305020 14,0 2 3 4 5 6
Wheel leg + wheel Ø200 mm 511220 3,3 4 4 4 4 4
Diagonal brace 185-28-21 304321 1,9 8 12 16 20 24
Horizontal brace 185-4 304304 1,8 6 8 10 12 14
Triangular stabilizer up to 4.2m platf. height* 305660 4,0 2 0 0 0 0
Triangular stabilizer Standard 4000-Series 305662 7,3 0 2 2 2 2
Toe board set 1.35 x 1.85m 305580 9,7 1 1 1 1 1
1.35 x 1.85 m
Total weight(kg) including wooden platforms 135 185 228 272 315
1) If the tower is used as a freestanding tower in this configuration there have to be 4 stabilizers around it.
* To only be used for a platform height up to 4.2 m.
