Altrex 4100 - Configuration Table 4200:2,45 M

12 / 44
EN
IV.II Configuration table 4200:2,45m
NL
EN 1004-3-8/12-XXXD
1/2 (every 2 meter 1 platform, staggered)
Platform height (m) 2,2 4,2
1,2
6,2
1
8,2
1,2
10,2
1
12,2
1,2
Work height (m) 4,2 6,2 8,2 10,2 12,2 14,2
Description Art.no.
Weight
(kg)
Frame 135-28-4 303340 5,5 0 0 0 0 0 0
Frame 135-28-7 303370 9,1 2 4 6 8 10 12
Guardrail frame 135-20-2 303320 3,4 2 2 2 2 2 2
Platform 2.45m with trapdoor (wood) 305110 18,3 1 1 1 1 1 1
Platform 2.45m without trapdoor (wood) 305120 17,8 1 2 3 4 5 6
Wheel leg + wheel Ø200 mm 511220 3,3 4 4 4 4 4 4
Diagonal brace 245-28-16 304316 2,4 4 8 12 16 20 24
Horizontal brace 245-6 304306 2,2 6 8 10 12 14 16
Triangular stabilizer up to 4.2m platf. height* 305660 4,0 0 2 0 0 0 0
Triangular stabilizer Standard 4000-Series 305662 7,3 0 0 2 2 2 2
Toe board set 1.35 x 2.45m 305585 14,9 1 1 1 1 1 1
1.35 x 2.45 m
Total weight(kg) including wooden platforms 112 170 227 277 327 377
Platform height (m) 3,2
1
5,2
1,2
7,2
1
9,2
1,2
11,2
1
Work height (m) 5,2 7,2 9,2 11,2 13,2
Description Art.no.
Weight
(kg)
Frame 135-28-4 303340 5,5 2 2 2 2 2
Frame 135-28-7 303370 9,1 2 4 6 8 10
Guardrail frame 135-20-2 303320 3,4 2 2 2 2 2
Platform 2.45m with trapdoor (wood) 305110 18,3 1 1 1 1 1
Platform 2.45m without trapdoor (wood) 305120 17,8 2 3 4 5 6
Wheel leg + wheel Ø200 mm 511220 3,3 4 4 4 4 4
Diagonal brace 245-28-16 304316 2,4 8 12 16 20 24
Horizontal brace 245-6 304306 2,2 6 8 10 12 14
Triangular stabilizer up to 4.2m platf. height* 305660 4,0 2 0 0 0 0
Triangular stabilizer Standard 4000-Series 305662 7,3 0 2 2 2 2
Toe board set 1.35 x 2.45m 305585 14,9 1 1 1 1 1
1,35 x 2,45 m
Total weight(kg) including wooden platforms 158 215 265 315 365
1) If the tower is used as a freestanding tower in this configuration there have to be 4 stabilizers around it.
2) 2 extra horizontal braces and 1 extra platform are required for assembly.
* To only be used for a platform height up to 4.2 m.
