Altrex 4100 - Page 13

13 / 44
NL EN
2/4 (every 4 meter 2 platforms)
Platform height (m) 2,2 4,2
1,2
6,2
1
8,2
1,2
10,2
1
12,2
1,2
Work height (m) 4,2 6,2 8,2 10,2 12,2 14,2
Description Art.no.
Weight
(kg)
Frame 135-28-4 303340 5,5 0 0 0 0 0 0
Frame 135-28-7 303370 9,1 2 4 6 8 10 12
Guardrail frame 135-20-2 303320 3,4 2 2 2 2 2 2
Platform 2.45m with trapdoor (wood) 305110 18,3 1 1 2 2 3 3
Platform 2.45m without trapdoor (wood) 305120 17,8 1 1 2 2 3 3
Wheel leg + wheel Ø200 mm 511220 3,3 4 4 4 4 4 4
Diagonal brace 245-28-16 304316 2,4 4 8 12 16 20 24
Horizontal brace 245-6 304306 2,2 6 6 10 10 14 14
Triangular stabilizer up to 4.2m platf. height* 305660 4,0 0 2 0 0 0 0
Triangular stabilizer Standard 4000-Series 305662 7,3 0 0 2 2 2 2
Toe board set 1.35 x 2.45m 305585 14,9 1 1 1 1 1 1
1.35 x 2.45 m
Total weight(kg) including wooden platforms 112 148 227 255 328 355
Platform height (m) 3,2
1
5,2
1,2
7,2
1
9,2
1,2
11,2
1
Work height (m) 5,2 7,2 9,2 11,2 13,2
Description Art.no.
Weight
(kg)
Frame 135-28-4 303340 5,5 2 2 2 2 2
Frame 135-28-7 303370 9,1 2 4 6 8 10
Guardrail frame 135-20-2 303320 3,4 2 2 2 2 2
Platform 2.45m with trapdoor (wood) 305110 18,3 1 2 2 3 3
Platform 2.45m without trapdoor (wood) 305120 17,8 1 2 2 3 3
Wheel leg + wheel Ø200 mm 511220 3,3 4 4 4 4 4
Diagonal brace 245-28-16 304316 2,4 8 12 16 20 24
Horizontal brace 245-6 304306 2,2 6 10 10 14 14
Triangular stabilizer up to 4.2m platf. height* 305660 4,0 2 0 0 0 0
Triangular stabilizer Standard 4000-Series 305662 7,3 0 2 2 2 2
Toe board set 1.35 x 2.45m 305585 14,9 1 1 1 1 1
1.35 x 2.45 m
Total weight(kg) including wooden platforms 141 220 248 320 348
1) If the tower is used as a freestanding tower in this configuration there have to be 4 stabilizers around it.
2) 2 extra horizontal braces and 1 extra platform are required for assembly.
* To only be used for a platform height up to 4.2 m.
ROLLING TOWER 4200
