VI Ballast
In certain situations the tower always has to be provided with
ballast. The ballast table attached indicates in which situations
ballast has to be used. The correct amount of ballast discs
(art.no. 415271), is attached to the four uprights of the base
frame, by using the ballast holders (art.no. 415277).
RS 4100
1.85m 2.45m
inside outside inside outside
2.2m
0 0 0 0
3.2m 0 0 0 0
4.2m
0 0 0 0
5.2m 0 0 0 1
6.2m
0 0 0 1
7.2m
0 3 0 3
Platform
h
eight
8.
2m
0 3 0 3
RS 4200
1.85m 2.45m
inside outside Inside outside
2.2m
0 0 0 0
3.2m
0 0 0 0
4.2m 0 0 0 0
5.2m
0 0 0 0
6.2m 0 0 0 0
7.2m
0 6 0 2
8.2m 0 6 0 2
9.2m
0 n.a. 0 n.a.
10.2m
0 n.a. 0 n.a.
11.2m 0 n.a. 0 n.a.
Platform height
12.2m
0 n.a. 0 n.a.
VS 4400-POWER
inside outside
1.0m
0 0
1.8m 0 0
2.7m
0 0
3.5m 0 1
3.8m
0 1
P
latform
h
eight
5.
8m
0 2
