III Rolling Tower 4100
III.I Configuration table 4100
EN
Platform height (m) 2,2 3,2
1 2
4,2
1 2
5,2
1
6,2
1
7,2
1 2
8,2
1 2
Work height (m) 4,2 5,2 6,2 7,2 8,2 9,2 10,2
Description Art.no.
Weight
(kg)
Frame 75-28-4 303440 3,8 0 2 0 2 0 2 0
Frame 75-28-7 303470 6,4 2 2 4 4 6 6 8
Guardrail frame 75-20-2 303420 2,6 2 2 2 2 2 2 2
Platform 1.85m with trapdoor (wood) 305010 14,0 1 1 1 2 2 2 2
Wheel leg + wheel Ø200 mm 511220 3,3 4 4 4 4 4 4 4
Diagonal brace 185-28-21 304321 1,9 2 4 4 6 6 8 8
Horizontal brace 185-4 304304 1,8 6 6 6 10 10 10 10
Triangular stabilizer up to 4.2m platf. height* 305660 4,0 0 2 2 0 0 0 0
Triangular stabilizer Standard 4000-Series 305662 7,3 0 0 0 2 2 2 2
Toe board set 0.75 x 1.85m 305565 7,6 1 1 1 1 1 1 1
0.75 x 1.85 m
Total weight (kg) including wooden platforms 67 87 92 131 136 148 153
Platform height (m) 2,2 3,2
1 2
4,2
1 2
5,2
1
6,2
1
7,2
1 2
8,2
1 2
Work height (m) 4,2 5,2 6,2 7,2 8,2 9,2 10,2
Description Art.no.
Weight
(kg)
Frame 75-28-4 303440 3,8 0 2 0 2 0 2 0
Frame 75-28-7 303470 6,4 2 2 4 4 6 6 8
Guardrail frame 75-20-2 303420 2,6 2 2 2 2 2 2 2
Platform 2.45m with trapdoor (wood) 305110 18,3 1 1 1 2 2 2 2
Wheel leg + wheel Ø200 mm 511220 3,3 4 4 4 4 4 4 4
Diagonal brace 245-28-21 304316 2,4 2 4 4 6 6 8 8
Horizontal brace 245-4 304306 2,2 6 6 6 10 10 10 10
Triangular stabilizer up to 4.2m platf. height* 305660 4,0 0 2 2 0 0 0 0
Triangular stabilizer Standard 4000-Series 305662 7,3 0 0 0 2 2 2 2
Toe board set 0.75 x 2.45m 305570 13,7 1 1 1 1 1 1 1
0.75 x 2.45 m
Total weight (kg) including wooden platforms 81 102 111 153 158 171 176
1) If the tower is used as a freestanding tower in this configuration there have to be 4 stabilizers around it.
2) 2 extra horizontal braces and 1 extra platform are required for assembly.
* To only be used for a platform height up to 4.2 m.
ROLLING TOWER 4100
