4. INSTALLATION
Figure 60: I/O Connector Block Removal Nexto Modules
The removal of Nexto Jet module connector has a different procedure, once that there is no frontal cover with extraction
lever. So to remove the connector from the Nexto Jet modules should be made a movement as shown in figure below, using the
wire-holder as an assistant to disconnect the lower part of the connector from the module and after that remove the connector
completely.
57
