4. INSTALLATION
Figure 69: Rack Connector Cover Removal
4.2.6. Electric Installation
DANGER:
At executing any installation in an electric panel, certify if the panel general power source is
OFF.
4.2.7. Spring-Connectors
This type of connector has a fixation system based on a high reliability spring even under vibration subjected environment
(Figure 70 and Figure 71). For its assembly it’s recommended the use of a 3.5 mm wide screwdriver with isolated handle
(Figure 72). The advantage of using this connector is the quick and easy electric cable assembly.
65
