4. INSTALLATION
4.2.7.2. 6-Pin Connector Block – NX9401
It’s recommended the use of 2.5 mm
2
cables. Each cable must be cut with a difference of 4 mm as indicated on Figure 73.
Each pin must have 2.5 mm
2
terminals crimped.
ATTENTION:
Use terminal with length A = 12 mm to guarantee the effective contact (see Figure 74)
4.2.7.3. 10-Pin Connector Block – NX9402
It’s recommended the use of 1.5 mm
2
cables. Each cable must be cut with a difference of 8 mm as indicated on Figure 73.
Each pin must have 1.5 mm
2
terminals crimped.
ATTENTION:
Use terminal with length A = 12 mm to guarantee the effective contact (see Figure 74).
4.2.7.4. 20-Pin Connector Block - NX9403
It’s recommended the use of 0.5 mm
2
cables. Each cable must be cut with a difference of 4 mm as indicated on Figure 73.
Each pin must have 0.5 mm
2
terminals crimped.
ATTENTION:
Use terminal with length A = 8 mm to guarantee the effective contact (see Figure 74).
4.2.7.5. 6-Pin Connector Block with Fixation – NX9404
It’s recommended the use of 0.5 mm
2
cables. Each cable must be cut with a difference of 4 mm as indicated on Figure 73.
Each pin must have 0.5 mm
2
terminals crimped.
ATTENTION:
Use terminal with length A = 8 mm to guarantee the effective contact (see Figure 74).
4.2.7.6. 12-Pin Connector Block with Fixation – NX9405
It’s recommended the use of 0.5 mm
2
cables. Each cable must be cut with a difference of 4 mm as indicated on Figure 73.
Each pin must have 0.5 mm
2
terminals crimped.
ATTENTION:
Use terminal with length A = 8 mm to guarantee the effective contact (see Figure 74).
4.2.7.7. 18-Pin Connector Block with Fixation – NX9406
It’s recommended the use of 0.5 mm
2
cables. Each cable must be cut with a difference of 4 mm as indicated on Figure 73.
Each pin must have 0.5 mm
2
terminals crimped.
ATTENTION:
Use terminal with length A = 8 mm to guarantee the effective contact (see Figure 74).
