ADJUSTMENT
Table 7. Adjustment
Settings
indication
Settings description
Operation mode
The selected mode adjusts the operation logic:
—manual. The door opening and closing is performed by pressing and holding the
button or on the control unit front panel, as well as pressing and holding control
devices, connected correspondingly to inputs ‘OP’ and ‘CL’. Remote controls commands
are ignored. Safety devices are activated.
—semi-automatic1. When button or control devices, connected to
input ‘OP’, are pressed for a short period the door moves in the sequence
‘Open—Stop—Close—Stop —Open …’. When button or control devices, connected
to input ‘CL’, are pressed for a short period the door moves in the sequence
‘Close—Stop—Close—Stop …’. The control of the door movement from remote controls
AT-4 / AT-4N / AT-4A is performed in the sequence ‘Open—Stop—Close—Stop …’.
Safety devices are activated.
—semi-automatic2. When button or control devices, connected to input ‘OP’, are
pressed for a short period the door moves in the sequence ‘Open—Stop—Open—Stop …’.
When button or control devices, connected to input ‘CL’, are pressed for a short
period the door moves in the sequence ‘Close—Stop—Close—Stop …’. The control of
the door movement from remote controls AT-4N / AT-4A is performed in the sequence
‘Open—Stop—Close—Stop …’.
Y
AT-4 remote controls are not used in this mode.
Safety devices are activated.
Default settings.
—automatic. After full opening of the door, followed by the countdown of the
pause time, set in the settings (settings ‘Pausetime’) the door closes automatically. The
activation of button or control devices, connected to input ‘OP’, as well as recorded
remote controls AT-4, leads to a full opening of the door, except for commands from
the devices mentioned, other commands are ignored until full opening of the door; the
activation of these control devices during pause time countdown to automatic closing of
the door results in the pause time reset and pause time countdown to start anew; when
the door is closing the control command causes movement to stop. When button or
control devices, connected to input ‘CL’, is pressed for a short period the door moves in
the sequence ‘Close—Stop—Close—Stop …’. Remote control (AT-4N / AT-4A), from which
the rst command to open has been given, controls the movement in the sequence
‘Full opening—Close—Stop—Full opening …’. Safety devices are activated.
The activation (beam interruption) of the photocells, connected to the input ‘PH1’, when
the door is fully open, results in the reset of the pause time to automatic closing of the
door and pause time countdown from the beginning after the release (beam continuity
recovery). If photocells, connected to input ‘PH1’, are activated, when the door is fully
open, the function (setting ‘Pause time’) of automatic door closing in ve seconds after
the photocells release activates.
Movement start delay time (output ‘FL’)
Setting the door movement start delay time and the operation mode of the lamp,
connected to output ‘FL’:
—OFF. The door starts moving based on the control command without a delay.
Thelamp illuminates only when the door is moving.
Default settings.
—ON. The lamp illuminates after the control command is given during a 3-second
door delay and when the door is moving.
