ELECTRONIC MODULE
4. ELECTRONIC MODULE
A main electronic module (g. 2) is installed inside the unit body, to which the drive system
devices are connected.
FU2
10A
FU1
10A
FU3
10A
FU4
800mA
HL2HL1
X9
OP.L
CL.L
X11
PH.T
PH1SE+24V+12V
SCL
OP
X10
X3
SL
FL
N
X2
WVUPE
M
3~
NL3L2L1
X1
8,2kOm /
OSE
Photo (NC)
Lamp1 Lamp2
Close (NO)
Open/SBS (NO)
STOP (NC)
Limit switch
OPEN (NC)
CLOSE (NC)
L3
L2 L1
3Р+N+PЕ /015/16A-6h
N
X6
A1
+-
F
CL
Learn
XN1
LR
OP.L
CL.L
CL OP SB
PH1S
MCID-2.6
Figure 2. Electronic module of the control unit
