5
Keyboard Installation and Operation
11. Numeric keypad - keys ranging from 0 to 9 that enable the user to select specific
cameras, monitors, presets, sequences, etc.
12. Monitor key - selects the monitor whose number was entered on the numeric
keypad.
13. Camera key - selects the camera whose number was entered on the numeric
keypad.
14. Alarm acknowledge key - acknowledges/clears an alarm displayed on the
currently active monitor.
15. Focus Near/Focus Far Key - adjusts the lens focus for the selected camera.
16. Open/Close Iris Key - opens or closes the lens iris for the selected camera.
17. Zoom In/Zoom Out Key - zoom in or zoom out with the selected camera.
18. Search key - places a DVR into search mode.
19. Telemetry enable/disable key - allows telemetry control (note, when the joystick
is moved, the keyboard automatically enters telemetry mode).
20. Reverse play key - places a VCR/DVR into reverse play mode.
21. Pause key - places a VCR/DVR into pause.
22. Direct Control key - calls a VCR/DVR to control.
23. Rewind key - places a VCR/DVR into rewind.
24. Fast forward key - places a VCR/DVR into fast forward.
25. Joystick
ADCC0200
2-axis joystick enables the user to pan and tilt, the selected camera.
ADCC0300
3-axis joystick enables the user to pan, tilt and zoom the selected
camera.
26. Enter key - used when in program mode.
27. Record key - places a VCR/DVR into record mode.
28. Stop key - stops playback of a VCR/DVR.
29. Start key - starts playback of a VCR/DVR.
30. Auxiliary 1 key - toggles auxiliary 1 between ON state and OFF state.
31. Auxiliary 3 key - toggles auxiliary 3 between ON state and OFF state.
32. Autopan key - starts autopan function for the selected camera (if function is
available).
