Page #49 background imageLoading...
Page #49 background image
41
Keyboard Installation and Operation
Appendix D: Specifications
Model Numbers
ADCC0200 .................. Keyboard with two-axis joystick
ADCC0300 .................. Keyboard with three-axis joystick
MP-CBL....................... Spare cable
MP-KMI ....................... Keyboard Matrix Interface
ADCCACPSN ............. US Remote Keyboard Kit
ADCCACPSP .............. EU/UK Remote Keyboard Kit
LCD
Size ............................. 16 x 2 white text on black background,
user adjustable
Controls
Keys ............................ 47 Tactile, color coded, rubberized keys
Joystick ....................... ADCC0200 - Two axis joystick for pan
and tilt control
ADCC0300 - Three axis joystick for
pan, tilt and zoom control and menu
navigation
Connectors
RS232, power ............. 2 x RJ45 to switcher/controller via
terminal block
Electrical
Supply voltage ............. 9 to 15V DC
Maximum current ......... 500mA
Mechanical
Dimensions ................. 13.4" x 5.2" x 3.2" (34.0 x 13.2 x 8.0 cm)
Weight (max.) .............. 3.3lb (1.5 kg)
Shipping weight ........... 4.2 lb (1.9 kg)
Construction ................ Mild steel/aluminum with ABS end caps
Color ........................... Black
Environmental
Operating temperature 0
O
to 30
O
C, 32
O
to 86
O
F
Storage temperature .... 0
O
to 40
O
C, 32
O
to 104
O
F
Operating humidity ...... 90% max, relative humidity, non-
condensing
Regulatory
Emissions .................... FCC Part 15, Subpart B Class A
CE: EN50081-1
Immunity ...................... CE: EN50130-4
