Chapter 5: Installer Functions
This chapter provides step-by-step instructions for keyboard installer functions. Installer
operations are accessed using the Special Configuration menu.
Entering the Special Configuration Menu
During the first five seconds after the unit is powered up, the display shows the current
software version number, the selected baud rate, etc. Whilst in this state, the Special
Configuration menu may be accessed.
1. During the five seconds after power is connected, simultaneously press the
SHIFT (
) and CLEAR ( ) keys.
2. The LCD will display "Special Config"
Setting the Keyboard Address
1. Enter the Special Config menu.
2. Press the VCR REVERSE PLAY ( ) key.
3. At the "Enter keyboard address" prompt, enter the keyboard address required
(default is 1).
4. Press ENTER.
Setting the Number of Keyboard Retries
1. Enter the Special Config menu.
2. Press the VCR PAUSE ( ) key.
3. At the "Enter RS485 Retries" prompt, enter the number required (default is 3).
4. Press ENTER.
