User Interface | 4-3
Communication Protocol
Select AMETEK Serial for inital PC communication setup.
Once communications with the analyzer are established, the
Modbus serial can be selected if desired.
When changing from AMETEK Serial to Modbus Serial, the analyzer communica-
tions parameters must be changed before the computer serial port settings.
Port Select the COM port on your computer where the connection
to the analyzer is installed.
Baud Rate Select the baud rate at which data will be transferred.
RS-232 Port Click if the analyzer is connected to an RS-232 port.
RS-485 Port Click if the analyzer is connected to an RS-485 port.
Address Type the network address to which the analyzer is connected.
Saving Your Settings
To save PC Communications settings, click OK.
To abort changes you have made, click Cancel.
Device
Refer to Figure 4-1.
Name Type in a name for the analyzer.
Description Type in a description for the analyzer.
Save Coniguration button
Save the analyzer’s internal parameters to a ile. The Save As
dialog box opens so that you can name and save the ile.
Restore Coniguration button
Restore the analyzer’s internal parameters from a ile. The
Open dialog box appears so that you can select and open the
ile.
The Restore Coniguration button can also be used to restore PC analyzer param-
eters.

NOTE

NOTE
