4-4 | 3050-SLR Moisture Analyzer
Live Data
Checked The system connects to and uses live data from the analyzer.
Not checked The system uses demonstration data.
Status
Indicates if the analyzer is on-line, off-line, or in demo mode.
On-Line The PC and analyzer are connected and communicating prop-
erly.
Off-Line The Live Data box is checked on the General tab and the
connection is broken or off-line.
Demo Mode The Live Data box is not checked on the General tab. No
analyzer is connected through the serial port. This allows you
to exercise program options without communication with the
analyzer.
Serial Numbers
The analyzer name and analyzer software version are displayed on the irst line in the upper
right-hand corner. The analyzer serial number and sensor serial number, and the mois-
ture generator and dryer codes are also displayed.
In the lower right-hand corner, above the Help button, is the Conigurator software ver-
sion number.
Saving Your Settings
To save settings on the General tab, click Apply.
To abort changes you have made, click Cancel. This will close the Conigurator software
program.
Clicking OK or CANCEL will close the conigurator application.
Device Communications Tab
For initial setup of PC communication parameters, use the Setup button on the
General tab.
NOTE
NOTE
