5-6 5000 Multi Point Moisture Analyzer
Table IV: Read and Write System Values (continued)
Configuration, Display, Alarm, and Output Flags
System Value Serial ID Description Path
Flags_1 F1 Binary value for 1st set of configuration flags
TEST/CONFIGLevel 2 Configure MenuFlags1
Flags_2 F2 Binary value for 2nd set of configuration flags
TEST/CONFIGLevel 3 Configure MenuFlags2
Line_1_Flag F3 Display flag for first line of display
TEST/CONFIGLevel 2 Configure MenuDisplay
Line_2_Flag F4 Display flag for second line of display
TEST/CONFIGLevel 2 Configure MenuDisplay
Line_3_Flag F5 Display flag for third line of display
TEST/CONFIGLevel 2 Configure MenuDisplay
Output1_Flag F6 Analog Flag for parameter linked to analog out 1
TEST/CONFIGLevel 2 Configure MenuAnalog
Output2_Flag F7 Analog Flag for parameter linked to analog out 2
TEST/CONFIGLevel 2 Configure MenuAnalog
Output3_Flag F8 Analog Flag for parameter linked to analog out 3
TEST/CONFIGLevel 2 Configure MenuAnalog
Output4_Flag F9 Analog Flag for parameter linked to analog out 4
TEST/CONFIGLevel 2 Configure MenuAnalog
Timers
System Value Serial ID Description Path
Cal_Time C1 Time of day for auto-cal
TEST/CONFIGSet Auto Cal Time
Cal_Timer C2 Seconds between cal cycles
TEST/CONFIGLevel 2 Configure MenuTiming
EquilCycl_1 C3 Equilibration cycles before SamplCycl_1
TEST/CONFIGLevel 2 Configure MenuTimingquil_Cycles
EquilCycl_2 C4 Equilibration cycles before SamplCycl_2
TEST/CONFIGLevel 2 Configure MenuTimingEquil_Cycles
EquilCycl_3 C5 Equilibration cycles before SamplCycl_3 TEST/CONFIGLevel 2 Configure MenuTimingEquil_Cycles
EquilCycl_4 C6 Equilibration cycles before SamplCycl_4 TEST/CONFIGLevel 2 Configure MenuTimingEquil_Cycles
EquilCycl_5 C7 Equilibration cycles before SamplCycl_5 TEST/CONFIGLevel 2 Configure MenuTimingEquil_Cycles
(Cal Cycle)
