3-4 5000 Multi Point Moisture Analyzer

Find Normal

Number Description Position Function

CR11 Red LED On/Off Indicates sample gas is flowing through cell

CR10 Red LED On/Off Indicates reference gas is flowing through cell

CR1 Red LED Blinking Indicates cell oven heater duty cycle

CR7 Red LED Off Indicates analyzer is in generator mode

CR14 Red LED Blinking Indicates moisture generator heater duty cycle

1 Sample gas flow control As Required Adjusts sample gas flow

2 Reference gas flow control As Required Adjusts reference gas flow

3 Moisture generator flow control As Required Adjusts moisture generator gas flow

(ccw increases flow)

4 Back pressure regulator control As Required Adjusts back pressure for all gases

5 Flowmeter As Calibrated Reads gas flow rate through cell

6 Back pressure gauge 103 kPa gauge Indicates gas back pressure

(15 psig)

S1 Moisture generator flow disable Open Disable moisture generator flow. Sample gas will

(Press & hold to flow instead to aid in sample gas flow rate

activate) adjustment

Field Unit Controls & Indicators

Numbers in parentheses in the text of this section correspond to find numbers of 5000

Field Unit controls and indicators shown in Table I and Figure 13.

Table I: 5000 Field Unit Controls and Indicators
