4 | P a g e
FRONT PANEL AND REMOTE DIGITAL PROGRAMMING
Voltage
±0.1% of full-scale output
Current
±0.4% of full-scale output
Overvoltage Protection (OVP)
±1% of full-scale output
REMOTE DIGITAL READBACK
Voltage
±0.15% of full-scale output
Current
±0.4% of full-scale output
REMOTE ANALOG PROGRAMMING
Constant Voltage ±0.25% of full-scale output for 0-5V range (±0.5% 0-10V range)
Constant Current ±0.8% of full-scale output
Overvoltage Protection (OVP) ±1% of full-scale output
REMOTE ANALOG READBACK
Voltage ±1% of full-scale output, 0-10V range
Current ±1% of full-scale output, 0-10V range
RESISTIVE
Constant Voltage (0-100%) 0–5 kΩ
Constant Current (0-100%) 0–5 kΩ
VOLTAGE
Constant Voltage (0-100%) 0–5 VDC or 0–10 VDC
Constant Current (0-100%) 0–5 VDC or 0–10 VDC
Overvoltage Protection (OVP) (5–110%) 0.25–5.5 VDC
REMOTE SENSING
Terminals are provided to regulate output voltage at point of load. Maximum
line drop 5% of rated output voltage per line for 40-100V models, 2% of rated
output voltage per line for >100V models.
REMOTE ANALOG CONTROL
Input to Output Isolation
The control signal return for Non-Isolated Analog programming is connected to
the negative output terminal. Under no condition should the negative terminal
exceed 300V to earth ground. The maximum voltage from control signal return
of the Remote Isolated Analog programming (option) to the negative output
terminal is 600V.
DIMENSION 3U MODELS 6U MODELS
WIDTH
19.00 in (48.3 cm) 19.00 in (48.3 cm)
DEPTH
25.46 in (64.7 cm) 25.12 in (63.8 cm)
HEIGHT
5.25 in (13.3 cm) 10.5 in (26.7 cm)
WEIGHT
(5kW) ≈ 40 lbs (18 kg) (20 KW) ≈ 120 lbs (54 kg)
(10kW) ≈ 60 lbs (27 kg) (25 kW) ≈ 140 lbs (64 kg)
(15kW) ≈ 80 lbs (36 kg) (30kW) ≈ 160 lbs (73 kg)
Important Notes:
1) Specifications are subject to change without notice
2) The SPS Series power supplies are intended for indoor use only.
