Ametek AMREL SPS Series User Manual

5 | P a g e
MODELS
Amperage PARD
1&2
Voltage 5 kW 10 kW 15 kW 20 kW 25 kW 30 kW
RMS P–P
0-40V 0-125A 0-250A 0-375A 0-500A
3
0-625A
3
0-750
3
20 mV 75 mV
0-60V 0-83A 0-167A 0-250A 0-333A 0-417A 0-500A 20 mV 75 mV
0-80V 0-63A 0-125A 0-188A 0-250A 0-313A 0-375A 20 mV 100 mV
0-100V 0-50A 0-100A 0-150A 0-200A 0-250A 0-300A 20 mV 100 mV
0-160V 0-31A 0-63A 0-94A 0-125A 0-156A 0-188A 25 mV 150 mV
0-200V 0-25A 0-50A 0-75A 0-100A 0-125A 0-150A 25 mV 175 mV
0-250V 0-20A 0-40A 0-60A 0-80A 0-100A 0-120A 30 mV 200 mV
0-330V 0-15A 0-30A 0-45A 0-61A 0-76A 0-91A 30 mV 200 mV
0-400V 0-12A 0-25A 0-38A 0-50A 0-63A 0-75A 40 mV 300 mV
0-600V 0-8A 0-17A 0-25A 0-33A 0-42A 0-50A 60 mV 350 mV
0-800V 0-6.2A 0-12.5A 0-18.7A 0-25A 0-31.2A 0-37.5A 80 mV 500 mV
1) P-P noise is measured across a 1uF capacitor at the end of a 6’ load cable with the supply operating at full load & at nominal input line voltage.
2) RMS noise is measured directly across the output terminals with the supply operating at full load and at nominal input line voltage.
3) Power level not available in 6U chassis. In 3U chassis, these power levels can be achieved up to 75kW by paralleling up to five power supplies. Note
that paralleling will increase Ripple and Noise.

Ametek AMREL SPS Series Specifications

General

Brand	Ametek
Model	AMREL SPS Series
Category	Power Supply
Language	English
