3-4 | Heated Acid Gas Sample Probe (Large Diameter)
Installing the Heated Acid Gas Sample Probe
This section describes how to retrofit an existing Sample Valve with
AMETEK’s HAG Sample Probe, and how to install a HAG Sample Probe
in new applications. Refer to the appropriate section for your installation
requirement.
The Sample Probe must be installed a minimum of two pipe diameters
away from any process piping component that causes process turbu-
lence, such as bends, valves, etc. Failure to comply with this recom-
mendation may result in an excessively noisy and therefore, errone-
ous, output signal.
To avoid plugging, do not install the Sample Probe horizontally.
IMPORTANT
Performing HAG Probe start-up and verification procedures re-
quires working from analyzer’s System 200 Configurator Software.
Familiarize yourself with the Software operations before installing
the HAG Probe. See “Navigating in the Software” in Chapter 4 of the
analyzer manual for more information.
!
CAUTION
NOTE
NOTE
