Ametek LAND LSP HD Series - 3 Services; Electrical Connections, Power Supply, and Network Settings

Page 16
User GuideLSPHD Linescanner Head
3 Services
3.1 Electrical connections: Cable requirements
TheconnectionbetweentheLandscanLSPHDHeadandLandscanpowersupplyunitsis
via an Ethernet cable.
Threepre-wiredcableassembliesareavailablefromLAND:
AMETEK Land
Part Nº
Length Sheath
material
Ambient limit Overall
diameter
805038 15m/49ft PU 105°C/221°F 7mm/0.26in
804977 15m/49ft Teon 200°C/392°F 7mm/0.26in
807087 30m/98ft PU 105°C/221°F 7mm/0.26in
CAUTION
Neverdisconnectthescannercablewhilstthescannerispowered.Doingso
coulddamageotherdevicesonthesameTCP/IPnetwork.Alwaysturnoff
poweratthePoweroverEthernetPSUpriortodisconnectingthescannercable.
Note
Thescannerendofthecableislabelled'Scanner'andisaright-angledM12
'D-coded'Ethernetconnector.
ThepowersupplyendofthecableisastraightM12'D-coded'Ethernetconnector.
3.1.1 Power supply units
• 807105LSPHDPowerOverEthernetSupplyModule
• 805037LSPHDPSU
• 805140 LSPHD Service Panel
3.1.2 Default Network Settings
IP Address: 10.1.10.100
Subnet: 255.255.0.0
EachscannerissuppliedwiththeIPaddresssettothedefaultof10.1.10.100.Thereis
aswitchonthedigitalPCBthatallowsthelastdigitoftheIPaddresstobechanged.
Iftheswitchissetinposition0,thelastdigitwillbeconguredbysoftware(thisisthe
default.)
Iftheswitchisinanyotherposition(7forexample),thentheaddresswillbecome
10.1.10.107,withalltheotherdigitssetinthesoftware.Softwareisconguredvia
theLandscanbrowseutility(Refertothehelple/userdocumentationsuppliedwiththe
software).
Amaximumof4clientsmaybeconnectedtothescanneratonetime.
