5.1 Setting the Emissivity value
Bydefault,theemissivityvalueissetremotelyviatheLandscanCongurationSoftware
orbyLandscanWCAsoftware,ifthisoptionisused.
Forfurtherinformation,seetherelevantUserGuide.
Alternatively,theemissivitysettingcanbesettoaxedvalueusingtheprocedure
below.
1) Unscrewthefourboltsholdingthescannersideplatestothebodyusinga5mm
allen/hexkey.
2) Noticethatthetwosidesofthescanneraredissimilarandidentifythe‘open’side
wheretheexternalpartsoftheopticalsystemcanbeclearlyseen.
3) Onthe‘open’sideofthescanner,ndthejumpermarkedJM3towardstheright
edgeofthePCB(showninsidegreencirclebelow).Removethejumperfromthe
PCB.
