User Guide LSPHD Linescanner Head
To reset the IP address back to 10.1.10.10x, press the laser button until the light goes
out,thenimmediatelyreleasethebutton.
3.1.3 Start-up time
Thescannerwillbeginitsstart-upwhenconnectedtoanappropriatepowersource.
Thescannertakesapproximately2minutestoboot,duringwhichtimeitwillnot
operate.
3.2 WaterRequirements(Water-CooledUnitsOnly)
IftheLSPLinescannerHeadistobeusedinanenvironmentwhereambient
temperaturesareabovethemaximumspecied,theAMETEKLandWater Cooled Air
Purgemountingaccessorymustbeused.
Thismountingaccessoryrequiresaconstantwatersupply.Thespecialmountingplate
hasinternalwaterchannelswithinowandoutowconnections(G1/8tappings)inthe
plate edge.
Thereisnopreferredoworientation.However,ifthescannerismountedinaposition
whereoneofthewaterconnectorsishigherthantheother,thenthelower connector
mustbeusedforthemainswaterin-ow.
The Water Cooled Mounting Plateissuppliedttedwithhoseconnectorssuitablefor
9.5mm/3/8inborewaterhose.Thewaterowraterequiredwilldependuponeach
individualapplication,but1litreperminute/0.26USgallonsperminuteisanabsolute
minimum,withamaximumwatertemperatureof30°C/86°F.
Themaximumwaterpressureis586kPa/85psi.
CAUTION
Ifthescannerisover-cooledtobelowthelocaldewpoint,condensationwillform
ontheunit.Thissituationmustalwaysbeavoided.
Thetemperatureofthecoolingwatermustbeintherangeof15to30°C/59
to 86 °F.
Aconstantsupplyofcleanwaterisrecommended,asthisreducesthelikelihood
ofblockageswithinthemountingplate.
