digiBASE
®
PMT Base with Integrated Bias Supply, Preamplifier and Digital Multichannel Analyzer 931003E / 0620
SHOW_ULD
Returns the value of the ULD, in channels, as a $C record.
Example Responses:
$C01023093 The ULD is 1023 (the maximum setting for the digiBASE).
SHOW_VERSION
Reports the digiBASE firmware version number in the form
Fmmmm-vvv<CR>
where mmmm is a 4-character model designator and vvv is a 3-character version designator.
Example Responses:
$FDBAS-001<CR> digiBASE firmware version 1 reported.
SHOW_WINDOW
Reports the start channel and number of channels in the window of interest, in the form
$Dxxxxxyyyyyccc<CR>
where xxxxx is the start channel (0 to [conversion gain ! 1]) and yyyyy is the number of
channels (1 to [conversion gain]). See SET_WINDOW for more information about the
window of interest.
Example Responses:
$D0000001024079<CR> Window of interest reported as starting at channel 0 and
continuing for 1024 channels.
$D0000001512080<CR> Window of interest reported as starting at channel 0 and
continuing for 512 channels (first 1/2).
$D0051200512088<CR> Window of interest reported as starting at channel 1024 and
continuing for 512 channels (last 1/2).
SHOW_ZERO_ADJUST
Returns percentage adjustment that has been applied by the stabilizer.
SHOW_ZERO_CHANNEL
Reports the current center channel for the stabilizer zero peak or zero if the zero channel has
not been set. See also SET_ZERO_CHANNEL.
Responses:
$C00000087<CR> Zero channel has not been set.
$C00002089<CR> Zero channel is channel 2 (lowest possible channel).
$C00250094<CR> Zero channel is channel 250.
SHOW_ZERO_STABILIZATION
Reports the state of zero peak stabilization. See also ENABLE_ZERO_STABILIZATION
and DISABLE_ZERO_STABILIZATION.
42
