Maintenance
— 44 SPECTRO ARCOS FHX3X — 08.02.2022
Inserting the plasma torch:
I. Insert the torch in the
appropriate position and
turn the lever (2) clockwise
until it snaps into place.
Fig. 17: Radial plasma observation
(SOP/DSOI)
The plasma torch has been
cleaned.
Fig. 18: Axial plasma observation
