Technical data
— 14 SPECTROCHECK — 07.05.2015
4 Technical data
Description Value
Instrument height 547 mm; 21.6"
Instrument width 510 mm; 20.1"
Instrument depth 865 mm; 34.1"
Instrument width (footprint) 395 mm; 15.6"
Instrument depth (footprint) 590 mm; 23.2"
Instrument weight approx 51 kg; 113 lbs
Power supply 95 – 240 V/ 50/60 Hz
Output during measurement (maximum) 400 VA
Power during stand-by 200 VA
Fuse 16 A (slow-blow)
Operating range
(permissible ambient temperature)
+10°C – +35°C; 50°F – 95°F
Air humidity range 20 – 80%, not condensing
Argon inlet pressure on the instrument 5.0 – 7.0 bar; 72 – 100 psi
Argon quality (min.) 4.8 (99.998% Ar) mit O
2
<3ppm, N
2
<10ppm,
H
2
O<5ppm, kW<1ppm
Argon flow rates Constant flow: 35 L/h
Analytic flow: 135 L/h
Storage conditions
(Ambient temperature)
-15 – +45°C; 5 – 113°F
