Description of instrument
SPECTROCHECK — 07.05.2015 — 9
2.3.3 Spark stand
No. Component No. Component
1 Outlet to filter system 5 Spark stand plate
2 Sample clamp 6 Spark stand orifice
3 Contact (movable) 7 Electrode (underneath spark
stand plate)
4 Locking wheel for contact 8 Spacer
1
2
3
4
5
6
7
8
