Serial Communications | A-21
6E/110 Dig_Input
Status of digital inputs(1=closed/on,
0=open/off)
bit 0 – CAL 0
IQ
bit 0 – Dig In
S2
bit 1 – CAL 1
IQ
Read only
6F/111
70/112 SysTst_Flag
System test that was preformed
1-Calibrate A/D
2-Ram Test
4-Test EEPROM
7-Erase Ram
8-Erase EEPROM
9- Test Watchdog
R/W
71/113 Passw Current password R/W
72/114 BoxCtl
IQ
Value that corresponds to the box set point
0 – 230 C
1 – 270 C
2 – 360 C
3 – Full on control
R/W
73/115 InjectGas
Turn on gas for inject cal gas menu
0 - Span gas
1 - Zero gas
2 - Comb gas
3 - Methane gas (if 3 span value RCU
installed)
4 - Process gas
R/W
74/116 Node_Addr The current node address R/W
75/117 Read only
76/118 Cmbsens Combust sensitivity associated with the
last calibration
Read only
77/119 Mthsens Methane sensitivity associated with the
last calibration
Read only
78/120 AFRatio The calculated A/F ratio Read only
79/121 AFRatio_CalSP The zero cal gas A/F ratio set point R/W
7A/122 Wobbe The calculated WOBBE value Read only
7B/123 Wobbe_SP The WOBBE Factor R/W
7C/124 Gas4_time Amount of time the methane span gas will
flow
IQ
(in seconds)
R/W
7D/125 AFRatio_CalSP2 The A/F Ratio set point at low end R/W
7E/126 XSO2Low_SP The XS O2 set point at low end R/W
7F/127 SW Version Current software version # Read only
