Controller / User Interface | 4-17
After you select one of these options, your choice will be confirmed on the
display:
Out # 1 will TRACK
during Calibration
or
Out # 1 will HOLD
during Calibration
For verify operations, select one of the following:
Track during Verify
or
Hold during Verify
After you select one of these options, your choice will be confirmed on the
display:
Out # 1 will TRACK
during Verify
or
Out # 1 will HOLD
during Verify
Set Current Mode
Define either a 0-to-20 or 4-to-20 mA analog output range for the selected
analog output port. This output is dependent on both the range of read-
ings you define and on the function you track on the analog output.
Setting the current mode
1. Select an analog output port.
2. From the Analog Range key, select Set Current Mode.
3. Select 4-to-20 mA Mode or 0-to-20 mA Mode. Default selection is 4-to-
20 mA.
