8 Rev. 7
Introduction
Specifications
Power Requirements
Primary: 100-120 or 200-240 VAC ±10%
50 - 60 Hz, 50 VA max
Memory Backup Battery: 3.6 Volt AA Lithium Cell
Physical
Dimensions: 89 mm H x 483 mm W x 191 mm D
(3.5" H x 19" W x 10.75" D)
Weight: 4.2 kg (9.2 lbs.)
Torque Limits on Current
Shunt Terminals:
5, 10, and 100 A models: 50 in-lbs.
200 A model: 150 in-lbs.
300 A model: 360 in-lbs.
Environmental
Ambient Temperature: Operating: 0 °C to 50 °C (32 °F to 122 °F)
Nonoperating: −20 °C to 60 °C (−4 °F to 140 °F)
Relative Humidity: 80% up to 31 °C (88 °F), decreasing
linearly to 50% at 50 °C (122 °F)
Altitude: 2 000 m (6562 ft.) Indoor use
Standards
EMI/EMC Standards: EN50082-1
EN61000-4-2
EN61000-4-3
EN61000-4-4
EN55022, Class A
Safety Standard: EN61010-1
Installation Category: Pollution Degree 2, Overvoltage Category II
as defined by IEC664
a. Resolution of the IEEE 754 double-precision floating point type consisting of a
52-bit fraction and 11-bit exponent.
