AMI 420 - Comm Setup Submenu

Rev. 7 49
Operation
Setup Menu : Comm
3.2.4 Comm Setup Submenu
The Comm submenu allows specification of parameters associated the
IEEE-488 and serial remote interfaces. Consult the Remote Interface
Reference section beginning on page 65 for more information regarding the
communication interfaces.
3.2.4.1 IEEE-488 Address
Specifies the IEEE-488 primary address of the Model 420. The
valid range is from 0 to 30. The Model 420 should be assigned a
unique primary address on the IEEE-488 bus. Enter a value or use
the dial to adjust the value. The default primary address is 22. The
Model 420 does not support secondary addressing.
3.2.4.2 Serial Baud Rate
Specifies the baud rate of the serial interface. Use the 237,21 key
to cycle between values. The default value is 9600 baud.
3.2.4.3 Serial Data Bits/Parity
Specifies the number of data bits and parity for the serial interface.
Use the
237,21 key to cycle between values. The default setting is
no 8 data bits/no parity.
3.2.4.4 Serial Stop Bits
Specifies the number of stop bits for the serial interface. Use the
237,21 key to cycle between values. The default value is 1 stop
bit.
$ × ,((($GGUHVV
9V  
$ × 6HULDO%DXG5DWH
9V    
$ × 6HULDO'DWD%LWV3DULW\
9V  (YHQ 2GG 1RQH
$ × 6HULDO6WRS%LWV
9V   
