Installation
Unipolar Supply with AMI Model 600/620 Energy Absorber
f. Connect the coaxial cable from the 352*5$0287 connector on
the back of the Model 420 to the BNC connector attached to the
terminal strip on the rear of the power supply (11).
g. Install an instrumentation cable between the magnet support
stand top plate connector (12) and the magnet station connector
J7A or J7B on the rear of the Model 420.
h. Install an instrumentation cable between the LHe/Temp connectors
J8A and/or J8B on the rear of the Model 420 and the Model 13x
Liquid Helium Level Instrument and/or temperature instrument
(13).
i. Remote communications via IEEE-488 and/or RS-232 (or optional
RS-422) can be accomplished by connecting suitable cabling to J11
and/or J12, respectively.
