Amprobe Europe GmbH AT-2000
- 23 -
S2600 Load Signal Generator
Operating Voltage: 9-600 volts AC or DC
Operating Frequency: 32.768 KHz
Duty Cycle: Transmits 2 pulses with a duration of 0.0625 each every
0.5 seconds
Current Output-
Low Mode: 35 mA peak, 4mA average
High Mode: 70 mA peak, 6mA average
Fuse: Fast acting 250mA @ 660V (6mm x 32mm)
Cat. No. 660.25-6X32
Case: Flame retardant ABS 911
Weight: 3.8 oz (108 grams)
T2200 Transmitter
Operating Frequency: 32.768 KHz
Duty Cycle: Transmits 2 pulses with a duration of 0.0625 each every
0.5 seconds.
Signal Output: 9V supply 24V supply
High Setting: 1A, 31V 3A 105V
Medium Setting: 1.8A, 13V 6A 45V
Low Setting: 3.0A, 6.5 10A 22V
Fuse: Fast acting 2A @ 250V 3AG 1/4" x 11/4"
Cat No. No. 2502-6x32
Battery: 9V alkaline- 24V jack will accept battery pack accessory
(B2024 or B2025)
Case: Flame retardant ABS 911
Weight: 6.4 oz (182 grams)
A2201 Clamp-on Transmitter Accessory
Operating Frequency: 32.768 KHz as supplied by the T2200
Case Breakdown Voltage: 3000 volts
Maximum Wiresize: 2000 MCM or 2" dia. cable
Battery: None, power is supplied by T2200
Weight: 9.9 oz (281 grams)
B2024 Battery Pack
Type: Nickel-Cadmium Rechargeable (20AA cells)
Capacity: 24Volt, 600 mah
Recharge Time: 14 hours
Fuse: Internal self-resetting
B2025 Recharger/Converter
Input: 115VAC
Output: 24VDC @ 350 mah
