7
M620
Series
Getting
Started
Assembly
1.
First, take the styrofoam container out of the cardboard carton and lay it on its side, paying attention
to which
side is labeled up. Remove the tape and open the container carefully so as to avoid dropping
and damaging the
optical items. Check carefully to ensure that all parts and accessories are intact.
2.
Check the packing list to ensure that you’re received all items:
-
One Monocular Microscope Body & Head
-
Four Objectives (4x, 10x, 40x, 100x)
-
10x Widefield Eyepieces
-
16x Widefield Eyepieces (for -A models only)
-
20x Widefield Eyepieces (for -B models only)
-
25x Widefield Eyepieces (for -C models only)
-
One Dust Cover
Note: LED models do not have a spare bulb, as the LED bulbs do not need replacing.
3.
Remove the microscope body from the box and remove the plastic protective covering. The body of
the micro-
scope is composed of the base, the stage, the arm, and the nosepiece.
4.
Screw the objectives into the microscope nosepiece from the lowest magnification to the highest,
again avoiding touching the lenses.
5.
Plug in the microscope and turn it on. If no light emerges from the light source, adjust the
dimmer knob on
the side of the base.
