9
M620
Series
Operation
Setting the Stage’s Stop-Limit
1.
To adjust the stop limit on the stage, unlock it by unscrewing the lower nut. The stop limit is located at the rear
of the stage.
2.
Once tension is released on the nut by rotating it counter clockwise, you may adjust the upper thumb screw to
move the limit up or down as desired.
3.
Lock the limit stop nut back into place after the desired stage height is achieved.
